| R-BAR: SMOOTH ROUND REINFORCING ROUND BARS IN LENGTHS AND BUNDLED | ||
| Purpose | Concrete reinforcement, commercial and manufacturing | |
| Packing | Secured with high tensile steel strapping at evenly spread intervals | |
| Bundle weight | ±1 000kg on shorter lengths and ±2 000kg on longer lengths | |
| Bar lengths | 6m / 12m / 13m – other lengths on application | |
| Diameters | Kg/m | Standard steel grades |
| 8.0mm (rolled straight or straightened from coil) | 0.395 | Mild steel commercial grade |
| 10.0mm (rolled straight or straightened from coil) | 0.617 | SANS 920 grade 250 |
| 12.0mm | 0.888 | BS 4449 grade 250 |
| 16.0mm | 1.580 | Other grades on application |
| 20.0mm | 2.470 | |
| 25.0mm | 3.850 | |
| 32.0mm | 6.310 | |
